Flat/stop squares
040521 Flange square NERIOX
Made of steel, zinc-plated. Uprights and flat sides processed.
Order ID Side lengths Flange width Profile Price EUR
mm mm mm
040521.0100 300 x 300 110 x 50 30 x 5 20.10
040521.0200 400 x 400 120 x 60 30 x 5 24.20
040521.0300 500 x 500 130 x 75 30 x 5 30.60
040535 NERIOX centring angle
DIN 875/I
Precision steel version with mm graduation on the scale. Ground functional sides ground, machined
flat sides.
Order ID Side lengths for shafts Ø Price EUR
mm mm
040535.0100 100 x 70 90 42.30
040535.0200 150 x 130 190 48.90
040535.0300 200 x 150 220 56.40
040556 Flat square NERIOX
DIN 875/II
Made of steel, with uprights and flat sides ground, inspection faces precision-ground. For use in
general shop applications.
Appropriate accessories:
140646 Wooden case NERIOX
Order ID Side lengths Profile Price EUR
mm mm
040556.0100 75 x 50 15 x 5 7.20
040556.0200 100 x 70 20 x 5 8.10
040556.0300 150 x 100 25 x 5 10.90
040556.0400 200 x 130 30 x 6 15.60
040556.0500 250 x 160 35 x 7 23.00
040556.0600 300 x 175 35 x 7 28.30
040556.0700 400 x 200 35 x 7 46.10
040556.0800 500 x 250 40 x 8 58.80
040556.0900 600 x 300 40 x 8 73.30
040556.1000 750 x 375 45 x 10 99.20
040556.1100 1000 x 500 50 x 10 148.40
040561 Try square NERIOX
DIN 875/II
Made of steel, with uprights and flat sides ground, inspection faces precision-ground. For use in
general shop applications.
Appropriate accessories:
140646 Wooden case NERIOX
Order ID Side lengths Profile Price EUR
mm mm
040561.0100 75 x 50 15 x 5 9.70
040561.0200 100 x 70 20 x 5 11.30
040561.0300 150 x 100 25 x 5 17.20
040561.0400 200 x 130 30 x 6 21.40
040561.0500 250 x 165 35 x 7 32.10
040561.0600 300 x 175 35 x 7 39.10
040561.0700 400 x 200 35 x 7 59.70
040561.0800 500 x 250 40 x 8 78.20
040561.0900 600 x 300 40 x 8 97.50
040561.1000 750 x 375 45 x 10 133.50
040561.1100 1000 x 500 50 x 10 198.50
